FIRE-GARD Glass-Clad Polycarbonate

Details

Rating: H.P. White HPW-TP-0500.02 Forced Entry Level 1; UL 9 Fire Test

SPECIFICATIONS

• MATERIAL

  Fire-Gard® Glass-Clad Polycarbonate

• nominal THICKNESS

  .870" In

• WEIGHT

  9.94 lbs per SF lbs/sq ft

Details

Rating: Fire Rating: UL Labeled for 3/4" hour in 1 hour rated masonry and door openings. UL File # KCMZ.R1.3833

SPECIFICATIONS

• MATERIAL

  Fire-Gard® Glass-Clad Polycarbonate

• nominal THICKNESS

  1.00" In

• WEIGHT

  10.81 lbs per SF lbs/sq ft

Details

Rating: H.P. White HPW-TP-0500.02 Forced Entry Level 2; WMFL 30 min forced entry; ASTM F1915 Security Grade 3; UL 10C Fire Test

SPECIFICATIONS

• MATERIAL

  Fire-Gard® Glass-Clad Polycarbonate

• nominal THICKNESS

  0.950 In

• WEIGHT

  9.5 lbs/sq ft

Details

Rating: WMFL 60 min forced entry; ASTM F1915 Security Grade 1; UL 9 Fire Test

SPECIFICATIONS

• MATERIAL

  Fire-Gard® Glass-Clad Polycarbonate

• nominal THICKNESS

  1.31" In

• WEIGHT

  12.66 lbs per SF lbs/sq ft

Details

Rating: WMFL 60 min forced entry; ASTM F1915 Security Grade 1; UL 10C Fire Test

SPECIFICATIONS

• MATERIAL

  Fire-Gard® Glass-Clad Polycarbonate

• nominal THICKNESS

  1.31" In

• WEIGHT

  12.66 lbs per SF lbs/sq ft
